• Pipeline products are manufactured in sizes ranging from 2” – 12”
  • Pressure capabilities up to 3500psi, depending on size and temperatures up to 100 °C/212°F
  • Used to transport highly corrosive produced water and CO2 gas
  • Used in lower to medium pressure oil and gas flow lines where corrosive flow is encountered
  • Available resin systems are anhydride, aliphatic amine and aromatic amine cured epoxy, with each providing slightly different chemical and temperature resistance
  • Fiberglass reinforcement provides the structural strength
  • Manufactured to a minimum design life of 20 years at rated temperature and pressure according to the ASTM D2992 Procedure B and industry standards, such as API 15HR

Applications

  • Flow / Emulsion lines
  • Injection / Disposal lines
  • Group lines
  • Gas gathering & transport lines
  • De-watering lines
  • Water/Frac water transfer lines

Benefits

  • Corrosion Control
  • Reduced Installation Costs
  • Improved Flow Efficiency
  • Reduced Paraffin & Scale Build-Up
  • Reduced Maintenance Cost
  • Environmentally Friendly Option

Oilfield Chemical Resistance Guide

TS&M Pipeline Questionnaire


STAR™ Super Seal SP/SPH/SS/SS-HP Standard Design (Anhydride, Aliphatic Amine & Aromatic Amine)

Product Description

  • Sizes - 2 through 12 inches
  • Pressure - Up to 3,000 psi (20.7 MPa)
  • Temperatures up to 212°F/100°C
  • Anhydride Resin System = up to 150°F (65.6°C) Max.
  • Aliphatic Amine Resin System= up to 200°F (93.3°C) Max.
  • Aromatic Amine Resin System = up to 212°F (100°C) Max.
  • Reinforcement - Premium Fiberglass
  • Joining Systems - O-ring / 4rd and 2rd connections
  • Joint Length - 30-37 feet (9-11 mts) nominal
  • Fittings - A variety of filament wound threaded fittings are available in 4rd and 2rd connections
STAR™ Super Seal SP/SPH/SS/SS-HP API Design (Anhydride, Aliphatic Amine & Aromatic Amine)

Product Description

  • Sizes - 2 through 12 inches
  • Pressure - Up to 3,000 psi (20.7 MPa)
  • Temperatures up to 212°F/100°C
  • Anhydride Resin System = up to 150°F (65.6°C) Max.
  • Aliphatic Amine Resin System= up to 200°F (93.3°C) Max.
  • Aromatic Amine Resin System = up to 212°F (100°C) Max.
  • Reinforcement - Premium Fiberglass
  • Joining Systems - O-ring / 4rd and 2rd connections
  • Joint Length - 30-37 feet (9-11 mts) nominal
  • Fittings - A variety of filament wound threaded fittings are available in 4rd and 2rd connections
STAR™ 8rd Aliphatic Amine Standard Design

Product Description

  • Pressure - Up to 4000 psi (27,6 MPa)
  • Resin System - Aliphatic Amine Cured Epoxy
  • Reinforcement - Premium Fiberglass
  • Joining Systems - API 8rd Threaded
  • Joint Length - 30 Feet (9,1 mts) Nominal Random Lengths of 20 to 32 Feet (6,1 to 9,8 mts)
  • Temperature - Up to 200° F (93.3° C) Maximum
  • Sizes - 1½ through 8 inches - API 8rd Thread
  • Fittings - A variety of filament wound API 5B threaded fittings are available.

Purchase all fittings by thread size and design pressure rating only.

STAR™ 8rd Anhydride Standard Design

Product Description

  • Pressure - Up to 3000 psi (20,7 MPa)
  • Resin System - Anhydride Cured Epoxy
  • Reinforcement - Premium Fiberglass
  • Joining Systems - API 8rd
  • Joint Length - 33 Feet (10,0 mts) Nominal
  • Random Lengths of 20 to 33 Feet (6,1 to 10,0 mts)
  • Temperature - Up to 150° F (65.6° C) Maximum
  • Sizes - 1½ through 8 inches
  • Fittings - A variety of filament wound API 5B threaded fittings are available.

Purchase all fittings by thread size and design pressure rating only.

STAR™ 8rd Aromatic Amine API Design

Product Description

  • Pressure - Up to 2500 psi (17.2 MPa)
  • Resin System - Aromatic Amine Cured Epoxy
  • Reinforcement - Premium Fiberglass
  • Joining Systems - API 8rd Threaded
  • Nominal Length of Joint - 30 Feet (9.1 mts)
  • Random Lengths of 20 to 32 Feet (6.1 to 9.8 mts)
  • Temperature - Up to 212°F (100°C) Maximum
  • Sizes - 1½ through 8 inches
  • Fittings - A variety of filament wound API 5B threaded fittings are available. API 15HR design systems require higher rated fittings, refer to the STAR High Pressure Threaded Fittings Product Data sheet. Temperature interpolation is not recommended for fittings.
